Diamond Series Ceiling Fan
Description
The overall design of Diamond Series, inspired by diamond’s seamed edge shape, is a graded shape from octagon to circle, which completed perfectly transition from fan blade to bottom circle. The design of central dissolving edge shows extremely luxurious; the graceful curve of tail end makes the overall tough shape with some dynamism; in the bottom, we adopt the design of aircraft engine turbine, enhancing the beauty of movement. The overall look shows a sense of modern, scientific, dynamic and safe. Apart from practical, it’s a extremely featured ornament and a work of art as well.
Features
- Solid - Use high-strength material, such as forged steel, aircraft grade aluminum, solid & safe
- Brilliant - Use fluorocarbon paint technology, high gloss in appearance, brilliant under the light
- High capacity of heat-transmission - Featured turbine air-suction effect, improving heat-dissipation
- Long-life - Use the most qualified components, ensure more than 15-year service life
- Fancy - Large-scale production, high-integrated, decline in cost, fancy but not expensive
Specification
| Model |
SHVLS-D8BAA42 | SHVLS-D8BAA36 | SHVLS-D8BAA30 | SHVLS-D8BAA24 |
| Size | 14ft（4.2m） | 12ft（3.6m） | 10ft（3.0m） | 8ft（2.4m） |
| Air Volume | 7550m³/min | 6560m³/min | 5530m³/min | 4550m³/min |
| Max. Speed | 80RPM | 90RPM | 100RPM | 120RPM |
| Fan Weight | 41kg | 38kg | 35kg | 31kg |
| Power | 0.4KW | 0.3KW | 0.2KW | 0.15KW |
| Full Load Current | 2.0Amps/220V | 2.0Amps/220V | 2.0Amps/220V | 2.0Amps/220V |
| Noise Level | 43dB (A) | 43dB (A) | 43dB (A) | 43dB (A) |
