EURUS III Series Ceiling Fan
Description
EURUSIII series fan is based on the development of the PMSM (permanent magnet synchronous motor) technology. The maximum diameter can be up to 7.3 meters.The product combines aerodynamic technology, transmission dynamics, PWM control technology, mechanical mechanics, simulation technology, communication control, industrial design and other comprehensive disciplines.It can promote the circulation of air flow in high efficiency, achieve the purpose of lowering the temperature of personnel, and greatly improve the environmental comfort.
Features
- Solid - Use high-strength material, such as forged steel, aircraft grade aluminum, solid & safe
- Brilliant - Use fluorocarbon paint technology, high gloss in appearance, brilliant under the light
- High capacity of heat-transmission - Featured turbine air-suction effect, improving heat-dissipation
- Long-life - Use the most qualified components, ensure more than 15-year service life
- Fancy - Large-scale production, high-integrated, decline in cost, fancy but not expensive
Specification
| Model | HVLS-D6AAA73 | HVLS-D6AAA61 | HVLS-D6AAA55 | HVLS-D6AAA49 |
| Size | 24ft (7.3m) | 20ft (6.1m) | 18ft (5.5m) | 16ft (4.9m) |
| Air Volume | 14800m³/min | 12900m³/min | 12200m³/min | 11500m³/min |
| Max. Speed | 56RPM | 60RPM | 65RPM | 75RPM |
| Fan Weight | 135kg | 129kg | 120kg | 115kg |
| Power | 1.5KW | 1.1KW | 0.9KW | 0.8KW |
| Full Load Current | 6.8Amps/220V | 5.0Amps/220V | 4.1Amps/220V | 3.6Amps/220V |
| Noise Level | <40dB> | <40dB> | <40dB> | <40dB> |
